Ebm-papst W2S130-AA03-77 Axial Fan 150mm 115VAC 2800RPM High Performance

Product: Ebm-papst W2S130-AA03-77 Axial Fan 150mm 115VAC 2800RPM High Performance

Specifications:
– Fan Type: Axial
– Size / Dimension: 150mm x 150mm x 55mm
– Voltage: 115 VAC
– Operating Frequency: 50/60 Hz
– Power Rating: 38 W
– Speed: 2800 RPM (at 60Hz), 2400 RPM (at 50Hz)
– Air Flow: 190 CFM (at 60Hz), 160 CFM (at 50Hz)
– Noise Level: 55 dBA
– Bearing Type: Ball
– Material – Frame: Die-cast aluminum
– Material – Impeller: Sheet steel, coated in black
– Termination: Terminal block
– Operating Temperature: -20°C to +70°C
– Protection Class: IP20
– Weight: 1.2 kg
– Certification: UL, CSA, CE
– RoHS compliant: Yes

Key Features:
– Sickle blade profile for enhanced airflow and reduced noise
– Maintenance-free ball bearing system for long service life
– Robust and durable construction with high-quality materials
– Equipped with terminal block for easy connection
– Direction of rotation is clockwise, seen on rotor
– Motor protection through thermal overload protector with automatic reset
– Can be controlled via external electronics
– Designed for continuous operation (S1)
– Impedance protected against overloading

Models Suitability:
– Suitable for a wide range of cooling and ventilation applications including industrial control cabinets, inverters, machinery, and automotive systems.
– Ideal for environments requiring high airflow and reliability, such as telecom equipment, medical devices, and data center cooling.
– Can be used in applications where space is at a premium due to its compact size.
– Appropriate for use in high-temperature settings due to its wide operating temperature range.
– Compatible with variable speed control for applications requiring adjustable airflow.
– Often utilized in renewable energy systems such as solar inverters and wind power converters to ensure optimal operating temperatures and efficiency.
