Ebm-papst W2S130-AA03-21 Axial Fan 150mm 115VAC 2800RPM High Performance

Product: Ebm-papst W2S130-AA03-21 Axial Fan 150mm 115VAC 2800RPM High Performance

Specifications:
– Fan Type: Axial
– Size / Dimension: 150mm x 150mm x 55mm
– Voltage: 115 VAC
– Operating Frequency: 50/60 Hz
– Power Rating: 38 W
– Speed: 2800 RPM (at 60Hz), 2400 RPM (at 50Hz)
– Air Flow: 190 CFM (at 60Hz), 160 CFM (at 50Hz)
– Noise Level: 55 dBA
– Bearing Type: Ball
– Material – Frame: Die-cast aluminum
– Material – Blades: Sheet steel, coated in black
– Weight: 1.2 kg
– Connection: Terminal pins
– Motor: External rotor shaded-pole motor
– Protection Class: IP20
– Insulation Class: Class B
– Operating Temperature: -20°C to +70°C
– Approval: VDE, CSA, UL, CE
– Mounting Position: Any
– Expected Life: 50,000 hours at 40°C

Key Features:
– Robust and durable construction ensuring a long service life
– High airflow and static pressure performance for demanding applications
– Compact design suitable for tight spaces
– Low energy consumption for efficient operation
– Easy to install with terminal pins for electrical connection
– Maintenance-free ball bearing system
– Resistant to harsh environmental conditions
– Equipped with thermal overload protection
– Compliant with international safety standards

Model Suitability:
The Ebm-papst W2S130-AA03-21 Axial Fan is suitable for a wide range of applications where efficient cooling or ventilation is required. These include but are not limited to:
– Industrial control cabinets
– Welding machines
– Heat exchangers
– Machinery cooling systems
– Ventilation systems for electronics
– HVAC systems
– Automotive applications
– Renewable energy systems such as solar inverters
– Food and beverage industry equipment
– Medical devices requiring reliable thermal management
