Ebm-papst W2E250-HJ28-01 Axial Fan 280mm 230VAC High Performance Robust Design

Product: Ebm-papst W2E250-HJ28-01 Axial Fan 280mm 230VAC High Performance Robust Design

Full Specifications:
– Nominal voltage: 230 VAC
– Frequency: 50/60 Hz
– Nominal speed: approx. 2550 min⁻¹ (at 50 Hz), approx. 2750 min⁻¹ (at 60 Hz)
– Power input: 190 W (at 50 Hz), 215 W (at 60 Hz)
– Current draw: 0.85 A (at 50 Hz), 0.92 A (at 60 Hz)
– Max. ambient temperature: -20°C to +70°C
– Airflow: 1080 m³/h (at 50 Hz), 1230 m³/h (at 60 Hz)
– Fan impeller material: Sheet steel, coated in black
– Housing material: Die-cast aluminum
– Motor protection: Thermal overload protector (TOP) connected to the windings
– Connection: 2 flat-pin connectors 2.8 x 0.5 mm, with grounding lug for M4 x 8 screw
– Direction of rotation: Clockwise, seen on rotor
– Type of protection: IP54
– Insulation class: F
– Mounting position: Any
– Mass: 3.5 kg
– Sound pressure level: 68 dB(A) (at 50 Hz), 71 dB(A) (at 60 Hz)

Key Features:
– Sickle-shaped fan blades ensure optimal airflow and cooling performance
– Robust design suitable for demanding applications
– Maintenance-free ball bearings for long service life
– Integrated motor protection for enhanced durability
– High efficiency with low energy consumption
– Easy to install with versatile mounting options
– Resistant to environmental factors with IP54 protection rating
– Suitable for continuous operation

Models Suitability:
– Industrial cooling systems
– Ventilation systems for electronic equipment
– Heat exchangers
– Air conditioning units
– Commercial refrigeration
– Welding machines
– Condensing units
– Cabinet cooling systems

The Ebm-papst W2E250-HJ28-01 Axial Fan is engineered for applications requiring robust, high-performance cooling solutions. Its design and construction make it an ideal choice for industries where reliability and efficiency are paramount.
