Ebm-papst W2E143-AB09-06 Axial Fan 2800RPM 115VAC High Performance Ball Bearing
$114.81
- Pricing: All prices are listed in U.S. dollars (USD).
- Secure Payments: We process payments securely through PayPal and Stripe.
- Free Shipping: Enjoy complimentary standard shipping within the United States (estimated delivery: 5–7 business days).
- International Shipping: For orders outside the U.S., please review our shipping policies for details.
Product: Ebm-papst W2E143-AB09-06 Axial Fan 2800RPM 115VAC High Performance Ball Bearing
Full Specifications:
– Manufacturer: Ebm-papst
– Product Category: Axial Fans
– Series: W2E143
– Part Number: W2E143-AB09-06
– Fan Type: Axial
– Supply Voltage: 115 VAC
– Operating Voltage Range: 85 to 135 VAC
– Frequency: 50/60 Hz
– Speed: 2800 revolutions per minute (RPM)
– Air Flow: 160 CFM (cubic feet per minute)
– Power Rating: 38 W
– Current Type: AC
– Bearing Type: Ball
– Noise Level: 55 dBA
– Frame Dimensions: 172 mm x 150 mm x 38 mm
– Frame Material: Die-cast aluminum
– Blade Material: Sheet steel
– Motor Protection: Impedance protected
– Termination: Terminal block
– Operating Temperature: -20°C to +70°C
– Weight: 1.2 kg
– Certification: UL, CSA, VDE, CE
– RoHS Compliant: Yes
– Life Expectancy: 65,000 hours at 40°C
Key Features:
– High-performance ball bearing system for extended service life and durability
– Robust die-cast aluminum frame construction ensuring stability and resistance to harsh conditions
– Efficient sheet steel blades designed for optimal airflow
– Impedance protection to safeguard the motor from overheating
– Terminal block for easy and secure electrical connections
– Compliance with multiple international safety standards, including UL, CSA, VDE, and CE
– RoHS compliance for environmental sustainability
– Suitable for operation in a wide temperature range, enhancing versatility in various applications
Models Suitability:
The Ebm-papst W2E143-AB09-06 Axial Fan is suitable for a wide range of applications where reliable and efficient cooling is required. These include but are not limited to:
– Industrial control cabinets
– Variable frequency drives
– Welding machines
– Heat exchangers
– Electronics cooling
– Ventilation systems
– Air conditioning units
– Refrigeration systems
– Medical equipment
– Renewable energy systems such as solar inverters and wind power converters
