Ebm-papst M2E068-CF Axial Fan 115VAC High Performance External Rotor Motor

Product: Ebm-papst M2E068-CF Axial Fan 115VAC High Performance External Rotor Motor

Full Specifications:
– Voltage: 115 VAC
– Frequency: 50/60 Hz
– Phase: Single-phase
– Power Input: 170 W
– Speed: 2550 RPM (at 60 Hz)
– Air Flow: 700 CFM (cubic feet per minute)
– Noise Level: 72 dB(A)
– Direction of Rotation: Clockwise, seen on rotor
– Type of Protection: IP44
– Insulation Class: F
– Motor Bearing: Ball bearing
– Connection: 2 leads, stripped ends
– Housing Material: Die-cast aluminum
– Impeller Material: Sheet steel, coated in black
– Weight: 4.5 kg
– Operating Temperature Range: -25°C to +60°C
– Approval: UL, CSA, CE
– Mounting Position: Any
– Lifetime: L10 life expectancy of 55,000 hours at 40°C

Key Features:
– High performance external rotor motor design for superior cooling efficiency
– Compact and robust construction for reliable operation in demanding conditions
– Integrated motor and impeller for space-saving installation
– Energy-efficient operation due to optimized aerodynamic impeller design
– Low noise emission for use in noise-sensitive environments
– Maintenance-free ball bearings for long service life
– Easy to connect with stripped lead wires
– Versatile mounting options to accommodate various applications
– Resistant to environmental factors with IP44 protection rating
– Compliance with international standards (UL, CSA, CE) for global use

Models Suitability:
The Ebm-papst M2E068-CF Axial Fan is suitable for a wide range of applications where efficient cooling or ventilation is required, including but not limited to:
– Electronic cabinet cooling
– Heat exchangers
– HVAC systems
– Refrigeration equipment
– Welding equipment
– Commercial and industrial ventilation systems
– Air purification and filtration units
– Agricultural ventilation systems
– Renewable energy systems such as solar inverters and wind turbines
