Ebm-papst DV5214/2NP Axial Fan 172x51mm 24VDC High Performance with Speed Signal

Product: Ebm-papst DV5214/2NP Axial Fan 172x51mm 24VDC High Performance with Speed Signal

Full Specifications:
– Dimensions: 172mm x 51mm
– Voltage: 24 VDC
– Type: Axial fan
– Bearing Type: Ball
– Airflow: 215.0 CFM (365 m³/h)
– Speed: 4800 RPM
– Power Consumption: 36 W
– Current Draw: 1.50 A
– Noise Level: 59 dB(A)
– Weight: 0.9 kg
– Material: Fiberglass-reinforced plastic; impeller PA, housing PBT
– Motor Protection: Locked rotor protection and polarity protection
– Connection: Stripped wires
– Speed Signal: Yes, provides a tachometer output
– Operating Temperature Range: -20°C to +70°C
– Expected Life: 65,000 hours at 40°C
– Compliance: RoHS, CE
– Protection Class: IP20

Key Features:
– High-performance motor ensures efficient cooling and airflow
– Robust design with durable ball bearings for extended service life
– Integrated speed signal for monitoring fan performance
– Locked rotor protection to prevent motor burnout
– Polarity protection to prevent incorrect electrical connection
– Energy-efficient operation with optimized blade design
– Easy to install with stripped wire leads for power connection
– Low noise output for applications sensitive to sound
– Suitable for use in a wide temperature range

Models Suitability:
– Industrial control cabinets
– Telecommunication equipment
– Frequency converters
– Solar inverters
– LED cooling systems
– Automotive applications
– Data center racks
– HVAC systems
– Medical devices requiring active cooling
– Any application requiring reliable and efficient 24VDC cooling solutions

The Ebm-papst DV5214/2NP Axial Fan is designed to meet the demanding requirements of various high-performance applications, providing a reliable and efficient cooling solution with advanced features such as speed monitoring and enhanced protection mechanisms.
