Ebm-papst 8452/2GHP Axial Fan 80x80x38mm 230VAC High Performance Sintec Sleeve Bearing

Product: Ebm-papst 8452/2GHP Axial Fan 80x80x38mm 230VAC High Performance Sintec Sleeve Bearing

Full Specifications:
– Dimensions: 80 x 80 x 38 mm
– Voltage: 230 VAC
– Frequency: 50/60 Hz
– Power Input: 12/11 W
– Current Draw: 0.11/0.10 A
– Speed: 2850/3400 RPM
– Air Flow: 50/60 m³/h
– Noise Level: 32/35 dB(A)
– Weight: 0.4 kg
– Connection: Terminal pins
– Housing Material: Die-cast aluminum
– Impeller Material: Sheet steel, coated in black
– Motor: Shaded-pole motor
– Bearing Type: High Performance Sintec Sleeve Bearing
– Direction of Rotation: Counter-clockwise, seen on rotor
– Protection Class: IP20
– Insulation Class: Class B
– Ambient Temperature Range: -20°C to +70°C
– Lifetime @ 40°C: 50,000 h
– Approval: VDE, CSA, UL, CE

Key Features:
– Sintec sleeve bearing technology for enhanced performance and durability
– Robust die-cast aluminum housing and high-quality sheet steel impeller
– Energy-efficient shaded-pole motor design
– Low noise emission for quiet operation
– High air flow and static pressure capabilities
– Easy to connect with terminal pins
– Counter-clockwise rotation for standard airflow direction
– Designed for continuous operation (S1)
– Thermal overload protector (TOP) wired internally for motor protection
– Maintenance-free and long service life
– Suitable for a wide range of ambient temperatures

Models Suitability:
– Ideal for high-performance cooling applications in electronics, telecommunications, and industrial systems
– Suitable for use in control cabinets, inverters, and welding machines
– Can be implemented in medical devices requiring quiet and reliable cooling
– Appropriate for ventilation and air conditioning systems
– Often used in automotive applications for cooling electronics under the hood
– Can be integrated into food and beverage equipment for consistent temperature regulation
