Ebm-papst 6224NHA Axial Fan 172x51mm 24VDC High Performance S-Force Series

Product: Ebm-papst 6224NHA Axial Fan 172x51mm 24VDC High Performance S-Force Series

Full Specifications:
– Model: 6224NHA
– Series: S-Force
– Fan Type: Axial
– Dimensions: 172mm x 172mm x 51mm
– Voltage: 24 VDC
– Current Type: DC
– Bearing Type: Ball
– Power Connection Type: Wire Leads
– Air Flow: 323.1 CFM (9.15 m³/min)
– Noise Level: 59 dBA
– Power Rating: 43 W
– Speed: 5500 RPM
– Static Pressure: 1.9 in H2O (472.7 Pa)
– Material: Fiberglass Reinforced Plastic (Impeller), Die-Cast Aluminum (Housing)
– Termination: Lead Wires
– Weight: 1.2 kg
– Operating Temperature: -20°C to +70°C
– Protection Class: IP20
– Approval: CE, UL, CSA, VDE
– Life Expectancy: 65,000 hours at 40°C

Key Features:
– High-performance compact design for maximum airflow
– S-Force technology for enhanced cooling efficiency
– Advanced aerodynamic blade design to reduce noise and increase performance
– Robust and durable construction with high-quality materials
– Energy-efficient motor design for reduced power consumption
– Speed controllable via external PWM signal
– Equipped with electronic protection against reverse polarity, blocking, and overloading
– Maintenance-free ball bearings for long service life
– Easy to install with wire leads for power connection

Models Suitability:
The Ebm-papst 6224NHA Axial Fan is suitable for a wide range of applications where high airflow and reliability are critical. These include but are not limited to:
– Telecommunications equipment
– Industrial automation and control cabinets
– Data center cooling systems
– Medical devices
– Automotive industry applications
– Renewable energy systems (e.g., solar inverters)
– High-density electronics cooling
– HVAC systems requiring high-performance air movement
