Ebmpapst 612 Axial Fan 60x60x25mm 24VDC Ball Bearing High Performance

Ebmpapst 612 Axial Fan 60mm 24VDC Ball Bearing

Specifications:

Dimensions: 60mm x 60mm x 25mm
Voltage: 24VDC
Bearing Type: Ball Bearing
Airflow: Dependent on specific model (e.g., 612 N/2HHL – 28.5 CFM / 48.3 m³/h)
Speed: Dependent on specific model (e.g., 612 N/2HHL – 4100 RPM)
Power Consumption: Dependent on specific model (e.g., 612 N/2HHL – 2.4W)
Noise Level: Dependent on specific model (e.g., 612 N/2HHL – 34 dB(A))
Operating Temperature Range: Typically -20°C to +70°C (Dependent on specific model)
Weight: Dependent on specific model
Materials: Plastic housing, metal impeller
Protection: Often IP44 (Dependent on specific model)
Connection: Typically wire leads (Dependent on specific model)

Key Features:

Compact Design: Suitable for space-constrained applications.
High Airflow: Efficient cooling performance.
Ball Bearing: Long service life and reliability.
Low Power Consumption: Energy-efficient operation.
Low Noise Level: Quiet operation for noise-sensitive environments.
Wide Operating Temperature Range: Suitable for various environments.

Model Suitability:

The Ebmpapst 612 series offers a wide range of models with varying performance characteristics. Specific model selection depends on the application requirements. Examples include:

612 N/2HHL: Commonly used in electronics cooling, HVAC systems, and telecommunications equipment.
Other 612 Series Models: Optimized for specific airflow, pressure, and noise requirements. Consult Ebmpapst’s documentation for detailed specifications and performance curves for each model within the 612 series to determine the best fit for your application. Factors to consider include required airflow, static pressure, operating voltage, and environmental conditions.
