Ebm-papst 4416M Axial Fan 119x119x38mm 24VDC 106CFM Ball Bearing High Performance

Product: Ebm-papst 4416M FAN

Full Specifications:
– Nominal voltage: 24 VDC
– Voltage range: 18 to 32 VDC
– Nominal speed: approx. 6300 RPM
– Power input: 5.5 W
– Airflow: 105.9 CFM
– Noise level: 47 dB(A)
– Bearing type: Sintec sleeve bearing
– Direction of rotation: Clockwise, viewed toward rotor
– Degree of protection: IP20
– Material: Fiberglass-reinforced plastic
– Fan impeller: Detachable, plastic PA (polyamide)
– Housing material: Die-cast aluminum
– Connection: Stripped wires
– Motor protection: Protected against reverse polarity and locking
– Weight: 0.4 kg
– Certification: VDE, CSA, UL, CE
– Ambient temperature range: -20°C to +70°C

Key Features:
– Energy-efficient GreenTech EC motor
– Compact design for space-saving installation
– Low power consumption for energy savings
– High airflow and static pressure performance
– Robust and durable construction
– Low noise emission for quiet operation
– Speed controllable via external PWM signal
– Advanced aerodynamic design for superior performance
– Locked rotor protection to prevent motor damage
– Reverse polarity protection for safe operation

Models Suitability:
– Suitable for a wide range of cooling applications in telecommunications, IT, industrial, and consumer electronics.
– Ideal for use in frequency converters, wind power converters, solar inverters, and medical devices.
– Appropriate for ventilation and air-conditioning systems.
– Can be used in automotive applications, including climate control and engine cooling.
– Designed for applications requiring high reliability and long service life, such as servers, networking equipment, and data centers.
– Compatible with various control systems for flexible integration into existing setups.
