Ebm-papst 4414HHR Axial Fan 119x119x38mm 24VDC 160CFM High Performance Ball Bearing
$47.43
- Pricing: All prices are listed in U.S. dollars (USD).
- Secure Payments: We process payments securely through PayPal and Stripe.
- Free Shipping: Enjoy complimentary standard shipping within the United States (estimated delivery: 5–7 business days).
- International Shipping: For orders outside the U.S., please review our shipping policies for details.
Product: Ebm-papst 4414HHR Axial Fan
Specifications:
– Voltage: 24 VDC
– Power: 5.8 W
– Current: 0.24 A
– Speed: 6300 RPM
– Airflow: 105.9 CFM
– Noise level: 47 dB(A)
– Bearing: Ball bearings
– Size: 119 x 119 x 38 mm
– Weight: 0.5 kg
– Material: Fiberglass-reinforced plastic
– Temperature range: -20°C to +70°C
– Life expectancy: 65,000 h
– Protection class: IP20
– Approvals: VDE, CSA, UL, CE
Key Features:
– S-Force high-performance technology
– Energy-efficient GreenTech EC motor
– Low noise emission
– Speed-controllable
– Intelligent electronics with motor protection
Suitability:
Ideal for telecommunications, data centers, industrial automation, medical devices, automotive, energy, HVAC, IT, and network systems.
Product: Ebm-papst 4414HHR FAN
Full Specifications:
– Nominal voltage: 24 VDC
– Nominal voltage range: 18-32 VDC
– Power input: 5.8 W
– Nominal current draw: 0.24 A
– Speed: 6300 RPM
– Airflow: 105.9 CFM
– Static pressure: 0.22 in H2O
– Noise level: 47 dB(A)
– Bearing type: Ball bearings
– Motor protection: Locked rotor protection and polarity protection
– Connection: Lead wires
– Fan frame size: 119 x 119 x 38 mm
– Weight: 0.5 kg
– Material: Fiberglass-reinforced plastic; PA impeller; housing PBT, UL94V-0
– Direction of rotation: Clockwise, viewed toward rotor
– Operating temperature range: -20°C to +70°C
– Life expectancy L10 at 40°C: 65,000 h
– Protection class: IP20
– Approval: VDE, CSA, UL, CE
Key Features:
– S-Force high-performance technology for demanding applications
– Compact design with impressive airflow and pressure performance
– Energy-efficient GreenTech EC motor for enhanced energy savings
– Robust and durable construction with high-quality ball bearings
– Advanced electronic commutation for extended service life
– Low noise emission for use in noise-sensitive environments
– Speed-controllable via analog (0-10V) or PWM signal
– Intelligent electronics with motor protection features
– Easy to integrate with standard fan dimensions and mounting points
Models Suitability:
The Ebm-papst 4414HHR FAN is suitable for a wide range of applications where high airflow and reliability are critical. These include but are not limited to:
– Telecommunications equipment
– Data center cooling systems
– Industrial automation and control cabinets
– Medical devices and healthcare equipment
– Automotive and transportation systems
– Energy and power supply units
– HVAC systems and refrigeration technology
– IT and network infrastructure
This fan is designed to meet the needs of applications that require both efficient cooling and low noise operation, making it a versatile choice for various high-performance electronic and industrial systems.
