Ebmpapst 3280JNPU Axial Fan 24VDC 48VDC 53CFM 6500RPM IP68 Protection
$69.00
- Pricing: All prices are listed in U.S. dollars (USD).
- Secure Payments: We process payments securely through PayPal and Stripe.
- Free Shipping: Enjoy complimentary standard shipping within the United States (estimated delivery: 5–7 business days).
- International Shipping: For orders outside the U.S., please review our shipping policies for details.
Ebmpapst 3280JNPU Axial Fan 24VDC 48VDC 53CFM 6500RPM IP68 Protection:
– Manufacturer: Ebmpapst
– Model Number: 3280JNPU
– Type: Axial Fan
– Nominal Voltage: 24VDC / 48VDC
– Airflow: 53 CFM
– Speed: 6500 RPM
– Power Consumption: 15.4W
– Bearing Type: Ball Bearings
– Dimensions: 92mm x 92mm x 38mm
– Material: Housing: Die-cast aluminum; Impeller: Glass-fiber reinforced PA plastic
– Protection Rating: IP68
– Operating Temperature Range: -20°C to +75°C
– Life Expectancy: 70,000 hours
– Weight: 0.28 kg
– Noise Level: 55 dBA
– Approvals: UL, CSA, CE, VDE
– Key Features: Dual Voltage Operation, High Airflow and Speed, IP68 Protection, Long Life Expectancy, Wide Operating Temperature Range, Robust Construction, PWM Control Input, Alarm Signal Output
– Model Suitability: Telecommunications Equipment, Industrial Automation, Outdoor Enclosures, Renewable Energy Systems, Transportation, Medical Equipment, Military and Aerospace, Any application requiring high-performance cooling in harsh environments.
Ebmpapst 3280JNPU Axial Fan 24VDC 48VDC 53CFM 6500RPM IP68 Protection:
Full Specifications:
Manufacturer: Ebmpapst
Model Number: 3280JNPU
Type: Axial Fan
Nominal Voltage: 24VDC / 48VDC (Dual Voltage Operation)
Voltage Range: 18…56 VDC
Airflow: 53 CFM (90 m³/h)
Speed: 6500 RPM
Power Consumption: 15.4W
Current Draw:0.64A at 24V, 0.32A at 48V
Bearing Type: Ball Bearings
Dimensions: 92mm x 92mm x 38mm
Material: Housing: Die-cast aluminum; Impeller: Glass-fiber reinforced PA plastic
Protection Rating: IP68 (Fully dust-tight and protected against continuous immersion in water)
Operating Temperature Range: -20°C to +75°C
Life Expectancy (L10 at 40°C): 70,000 hours
Connection: Wire leads, AWG 22, TR 64
Weight: Approximately 0.28 kg
Noise Level: 55 dBA
Approvals: UL, CSA, CE, VDE (depending on specific sub-model)
Key Features:
Dual Voltage Operation: Operates efficiently on both 24VDC and 48VDC systems.
High Airflow and Speed: Delivers substantial airflow at a high RPM for effective cooling.
IP68 Protection: Provides exceptional protection against dust and water ingress, suitable for harsh environments.
Long Life Expectancy: Ball bearings and robust construction ensure extended operational life.
Wide Operating Temperature Range: Suitable for use in a variety of temperature conditions.
Robust Construction: Die-cast aluminum housing and reinforced plastic impeller for durability.
PWM Control Input: Allows for speed control and adjustment based on cooling needs.
Alarm Signal Output: Provides a signal in case of fan failure or blockage.
Model Suitability:
Telecommunications Equipment: Cooling of base stations, network switches, and other telecom infrastructure.
Industrial Automation: Cooling of control cabinets, PLCs, and other industrial machinery.
Outdoor Enclosures: Ventilation and cooling of equipment exposed to the elements.
Renewable Energy Systems: Cooling of inverters, battery systems, and other components.
Transportation: Cooling of electronics in vehicles, trains, and other transportation applications.
Medical Equipment: Cooling of sensitive medical devices requiring reliable operation.
Military and Aerospace: Applications requiring rugged and reliable cooling solutions.
* Any application requiring high-performance cooling in harsh, dusty, or wet environments.
