Ebm-papst 4412/2HHP Axial Fan 119x119x38mm 24VDC High Performance Ball Bearing
$35.00
- Pricing: All prices are listed in U.S. dollars (USD).
- Secure Payments: We process payments securely through PayPal and Stripe.
- Free Shipping: Enjoy complimentary standard shipping within the United States (estimated delivery: 5–7 business days).
- International Shipping: For orders outside the U.S., please review our shipping policies for details.
Product: Ebm-papst 4412/2HHP Axial Fan 119x119x38mm 24VDC High Performance Ball Bearing
Specifications:
– Voltage: 24V DC
– Current Consumption: 630 mA
– Power Consumption: 7.6W
– Speed: 6300 RPM
– Air Flow: 108.3 CFM
– Static Pressure: 0.36 inH2O
– Noise Level: 47 dB(A)
– Bearing Type: Ball bearing
– Weight: 0.4 kg
– Dimensions: 119 x 119 x 38 mm
Key Features:
– High-performance motor
– Durable design
– Advanced aerodynamic blade
– Energy-saving operation
– Low noise emission
– Long service life
– Compact size
Suitability:
– Industrial control cabinets
– Telecommunication equipment
– Data center cooling systems
– Medical devices
– Automotive applications
– HVAC systems
– Electronic equipment cooling
– Inverter cooling
– Server racks
Product: Ebm-papst 4412/2HHP FAN
Full Specifications:
– Nominal Voltage: 12V DC
– Operating Voltage Range: 6 to 13.8V
– Nominal Current Consumption: 630 mA
– Power Consumption: 7.6W
– Speed: 6300 RPM
– Maximum Air Flow: 108.3 CFM
– Maximum Static Pressure: 0.36 inH2O
– Noise Level: 47 dB(A)
– Bearing Type: Ball bearing
– Motor Protection: Locked rotor protection and polarity protection
– Connection: Lead wires
– Fan Housing Material: Fiberglass-reinforced plastic (PBT)
– Impeller Material: Fiberglass-reinforced plastic (PA)
– Direction of Rotation: Clockwise, viewed toward rotor
– Weight: 0.4 kg
– Dimensions: 119 x 119 x 38 mm
– Life Expectancy L10 at 40°C: 65000 h
– Ambient Temperature Range: -20°C to +70°C
Key Features:
– High-performance motor with exceptional efficiency
– Robust and durable design suitable for demanding applications
– Advanced aerodynamic blade design for high airflow and static pressure
– Integrated electronic commutation for energy-saving operation
– Low noise emission due to optimized airflow and motor design
– Equipped with speed signal output for RPM monitoring
– Maintenance-free ball bearing system for long service life
– Compact size for easy integration into various applications
– Compliance with relevant international standards (e.g., UL, CSA, VDE, CE)
Models Suitability:
The Ebm-papst 4412/2HHP FAN is suitable for a wide range of applications where efficient cooling and air movement are critical. These include but are not limited to:
– Industrial control cabinets
– Telecommunication equipment
– Data center cooling systems
– Medical devices
– Automotive applications
– HVAC systems
– Electronic equipment cooling
– Inverter cooling for renewable energy systems
– High-density server racks
