Ebm-papst 424JH/2HPU Axial Fan High-Performance 2HP Ultra-Quiet Operation

Add your review

$76.08

Pricing: All prices are listed in U.S. dollars (USD).
Secure Payments: We process payments securely through PayPal and Stripe.
Free Shipping: Enjoy complimentary standard shipping within the United States (estimated delivery: 5–7 business days).
International Shipping: For orders outside the U.S., please review our shipping policies for details.

Ebm-papst 424JH/2HPU Axial Fan High-Performance 2HP Ultra-Quiet Operation features a 2 HP motor, 230 VAC, 50/60 Hz frequency, max 2750/3250 RPM speed, up to 1580 m³/h airflow, 424 mm fan diameter, ultra-quiet 65 dB(A) noise level, die-cast aluminum housing, IP54 protection, and CE/UL/CSA/RoHS/WEEE compliance.

Description

Product: Ebm-papst 424JH/2HPU Axial Fan High-Performance 2HP Ultra-Quiet Operation

Full Specifications:
– Motor Type: External rotor, shaded-pole motor
– Nominal Voltage: 230 VAC
– Frequency: 50/60 Hz
– Power Input: 2 HP (1.5 kW)
– Speed: Max 2750 RPM (50 Hz), 3250 RPM (60 Hz)
– Airflow: Up to 1580 m³/h at free air
– Fan Diameter: 424 mm
– Noise Level: Ultra-quiet operation, sound pressure level as low as 65 dB(A)
– Housing Material: Die-cast aluminum
– Blade Material: Profiled aluminum
– Protection Class: IP54, providing protection from dust and splash water
– Insulation Class: F
– Direction of Airflow: “V” direction (air out over struts)
– Connection: Terminal box with PG 13.5 cable gland
– Mounting Position: Any
– Weight: Approx. 17 kg
– Accessories: Inlet rings, guard grills, and speed controllers available separately
– Compliance: CE, UL, CSA, RoHS, WEEE

Key Features:
– High-performance operation with a powerful 2 HP motor
– Ultra-quiet design for noise-sensitive environments
– Energy-efficient with optimized airflow for maximum cooling
– Robust construction with die-cast aluminum housing and profiled aluminum blades
– Versatile mounting options for easy installation in various applications
– IP54 protection rating ensures durability against environmental factors
– Maintenance-free shaded-pole motor designed for continuous operation
– Speed-controllable to adapt to varying cooling requirements
– Thermal overload protection for motor safety

Models Suitability:
– Industrial cooling systems: Suitable for large-scale cooling applications requiring high airflow and low noise levels.
– Ventilation systems: Ideal for commercial and industrial ventilation where noise is a concern.
– Electronic cooling: Provides efficient cooling for electronic equipment racks and enclosures.
– HVAC: Applicable for integration into heating, ventilation, and air conditioning systems.
– Automotive: Can be used in automotive applications for engine or cabin cooling.
– Renewable energy systems: Suitable for cooling components in solar and wind energy installations.
