Ebm-papst 3214J/39NU Axial Fan 14VDC 280mA 3700RPM 153CFM IP68 Protection
$58.98
- Pricing: All prices are listed in U.S. dollars (USD).
- Secure Payments: We process payments securely through PayPal and Stripe.
- Free Shipping: Enjoy complimentary standard shipping within the United States (estimated delivery: 5–7 business days).
- International Shipping: For orders outside the U.S., please review our shipping policies for details.
Ebm-papst 3214J/39NU Axial Fan is a high-performance 14VDC fan with 3700RPM speed, 153CFM airflow, and IP68 protection. It features a ball bearing design, EC motor technology, and robust construction for durability. Ideal for harsh environments, high-performance cooling, automotive, transportation, and renewable energy applications.
Ebm-papst 3214J/39NU Axial Fan 14VDC 280mA 3700RPM 153CFM IP68 Protection:
Full Specifications:
Manufacturer: Ebm-papst
Part Number: 3214J/39NU
Type: Axial Fan
Nominal Voltage: 14 VDC
Voltage Range: 10 … 15 VDC
Current Consumption: 280 mA
Power Consumption: 3.9 W
Speed: 3700 RPM
Airflow: 153 CFM (260 m³/h)
Static Pressure: 0.512 in H2O (127.6 Pa)
Noise Level: 51 dB(A)
Bearing Type: Ball Bearing
Motor Protection: Electronically Commutated (EC) Motor, with integrated electronic protection against reverse polarity, locked rotor, and overload.
Material: Housing: Die-cast aluminum; Impeller: Fiberglass-reinforced PA plastic
Dimensions: 92mm x 92mm x 38mm
Weight: 280g
Operating Temperature Range: -40°C to +85°C
Storage Temperature Range: -40°C to +90°C
Life Expectancy (L10 at 40°C): 70,000 hours
Connection: 2 leads, AWG 22, TR 64
Approvals: UL, CSA, VDE, CE
Key Features:
IP68 Protection: Fully protected against dust ingress (IP6X) and suitable for continuous immersion in water under specified conditions (IPX8).
High Airflow and Pressure: Delivers substantial airflow and static pressure for demanding cooling applications.
Robust Construction: Die-cast aluminum housing and fiberglass-reinforced impeller ensure durability.
Long Life Expectancy: Ball bearing design and EC motor technology contribute to extended operational life.
Wide Operating Temperature Range: Suitable for use in extreme temperature environments.
Electronic Motor Protection: Safeguards against common electrical faults.
Compact Size: Standard 92mm frame size for easy integration.
Model Suitability:
Harsh Environments: Ideal for applications requiring resistance to dust, moisture, and extreme temperatures, such as outdoor enclosures, industrial machinery, and marine equipment.
High-Performance Cooling: Suitable for cooling electronics in demanding applications like servers, telecommunications equipment, and power supplies.
Automotive and Transportation: Can be used in automotive cooling systems, off-road vehicles, and other transportation applications.
Renewable Energy: Applicable in solar inverters, wind turbine control systems, and other renewable energy equipment.
* Any application requiring a reliable, high-performance, and environmentally protected 14VDC axial fan.
